Portable LED daim ntawv loj loj screen
Txaus siab rau kev siv ib leeg lossis sib sau ua ke ntau chav rau cov zaub loj, muab cov kev hloov pauv hloov tau yooj yim thiab tsis muaj kev txwv
| Specification | ||
| SHIPPING MARK | QHOV CHAW UA HAUJ LWM | TSEEM CEEB |
| N/M | INDOOR P1.86mm GOB Folding LED Poster, Nrog 2 tus neeg hais lus | Qhov Loj: 0.64mx 1.92m = 1.2288㎡ Tus Qauv Zauv: P1.86-43S Module Loj: 320 * 160mm Pixel Pitch: 1.86mm Pixels ceev: 289,050 dots / m2 Pixel Configuration: 1R1G1B Pob hom: SMD1515 Pixel daws teeb meem: 172 dots (W) * 86 dots (H) Qhov Pom Zoo Tshaj Plaws: 2M - 20M Vaj huam sib luag tam sim no: 3.5 - 4A Max zog: 20W Module Thickness: 14.7 hli Qhov hnyav: 0.369KG Tsav Hom: 16380 Constant Current Drive Scan hom: 1/43 Scan Chaw nres nkoj hom: HUB75E Brightness ntawm White Balance: 700cd / ㎡ Refresh zaus: 3840HZ |
| Control System (NOVA) | xa daim npav, NOVA TB40 | |
| txais daim npav, NOVA MRV412 | ||
| Pob | davhlau case | |
| Khoom seem | 1 pcs module | |
| tus nqi shipping | EXW LINHAI CITY | |
Ib qho khoom siv nkaus xwb yuav tsum tsis muaj kev teeb tsa nyuaj thiab npaj siv tom qab unpacking. Nws yog qhov tshwj xeeb tshaj yog tsim rau "qhov chaw me me, kev tshaj tawm ib leeg" cov xwm txheej thiab tuaj yeem hloov tau yooj yim cov ntawv tshaj tawm thiab cov ntxaij vab tshaus ruaj khov.
Lub portable tsim kom ntseeg tau tias tsis muaj kev txav mus los: hnyav li 0.369KG thiab ntsuas 14.7mm tuab, nws tuaj yeem nqa tau yooj yim hauv ib txhais tes. Zoo tagnrho rau cov khw muag khoom qhov rai, rooj txais tos, lossis chaw ua haujlwm so. Tsis muaj qhov xav tau rau kev teeb tsa - tsuas yog txav nws thaum twg xav tau. Piv txwv li, hloov nws mus rau qhov nkag thaum lub sij hawm kev tshaj tawm kom nyiam cov tsheb thauj mus los, ces txav mus rau tom khw tom qab qhov kev tshwm sim los nthuav tawm cov khoom tshiab.
Zog txuag hluav taws xob thiab tsis muaj teeb meem rau kev siv mus sij hawm ntev: Nrog lub zog siab tshaj plaws ntawm tsuas yog 20W thiab vaj huam sib luag tam sim no ntawm 3.5-4A (sib npaug rau lub teeb rooj), nws ua kom tsis muaj teeb meem nyiaj txiag txawm tias siv tas li. 16380 tus neeg tsav tsheb tsis tu ncua tam sim no lav ruaj khov, tsis muaj flicker-dawb illumination, tiv thaiv qhov muag tsis pom thaum txuas ntxiv. Zoo meej rau cov chaw ua haujlwm, khw muag khoom, thiab lwm yam kev saib xyuas ntau zaus.
Precision aiming rau compact saib xav tau kev pab: Qhov zoo tshaj plaws saib nyob deb li ntawm 2M mus rau 20M, zoo kawg nkaus haum rau khw ib puag ncig (1-3M rau cov neeg muas zaub), chaw txais tos (2-5M rau cov qhua), thiab cov rooj sib tham me me (5-10M rau cov neeg tuaj koom). Nrog 700cd / ㎡ dawb tshuav qhov ci ci, cov zaub tseem pom tseeb thiab tsis muaj qhov ci txawm nyob hauv nruab hnub ci ntsa iab ze qhov rais, tshem tawm qhov xav tau kom tsis txhob muaj teeb pom kev ncaj qha.
Yog tias tsis muaj pab pawg tshaj lij, ntau yam khoom siv tuaj yeem sib sau ua ke hauv txhua qhov loj ntawm lub vijtsam loj, yooj yim ua tau raws li cov kev xav tau ntawm kev nthuav qhia, kev ua ub no, chaw ua haujlwm loj thiab lwm yam "cov xwm txheej loj, tsis pom kev zoo", thiab daws qhov mob cov ntsiab lus ntawm cov ntxaij vab tshaus loj "siab customization nqi, tsis tuaj yeem rov qab siv dua".
Seamless kev koom ua ke nrog uninterrupted visuals: Featuring 320 × 160mm standardized modules thiab HUB75E universal ports, qhov system no tshem tawm lub cev tsis sib haum ntawm modules thaum txuas ntau chav nyob ntawm cov ntaub ntawv cables. Cov txiaj ntsig tau pom muaj kev txuas ntxiv, seamless kev pab cuam nrog kev ua tau zoo sib xws rau cov ntxaij vab tshaus loj loj.
Flexible screen configuration nrog customizable qhov ntev: Seamlessly yoog mus rau txhua yam scenario los ntawm combining 2-4 units. Ob chav nyob tsim ib daim ntawv ntev ntev rau cov lus hais ntawm cov npe, thaum plaub chav nyob tsim 5㎡ + zaub zoo tagnrho rau cov xwm txheej me. Tsis xav tau pab neeg tshaj lij - teeb tsa hauv 10 feeb. Unconstrained los ntawm qhov ntau thiab tsawg, nrog cov khoom tshwj xeeb rov siv dua. 3840Hz refresh npaum li cas kom ntseeg tau tias tsis muaj kev sib koom ua ke, tshem tawm cov lag luam hauv cov yeeb yaj kiab thiab cov ntawv scrolling. 1/43 scan hom nrog kev tsav tam sim no tau lees paub cov teeb pom kev zoo pixel ci ntsa iab thoob plaws tag nrho lub vijtsam, tiv thaiv qhov tsaus me ntsis thiab tswj xyuas qhov pom kev zoo ib yam.
Txawm hais tias nws yog ib lub tshuab lossis patchwork, cov duab zoo ib txwm nyob hauv online, los ntawm cov ntawv mus rau cov duab, txhua qhov kev nthuav dav tuaj yeem nthuav tawm kom meej, kom cov ntsiab lus tshaj tawm zoo nkauj dua.
Ultra-HD Pixel Resolution nrog Unmatched Detail: Featuring lub ultra-compact pixel suab ntawm 1.86mm thiab ib pixel ceev ntawm 289,050 cov ntsiab lus ib square meter - tshaj peb zaug siab dua li cov pa P4 cov ntxaij vab tshaus - qhov no technology muab tshwj xeeb clarity. Nws nthuav tawm cov ntaub ntawv zoo nkauj thiab cov ntawv luam tawm zoo kawg nkaus, muab cov ntaub ntawv muaj peev xwm ntau dua thiab muaj zog pom kev zoo dua li cov ntawv tshaj tawm.
Kev tsim cov xim muaj tseeb nrog cov xim zoo nkauj: Featuring 1R1G1B tag nrho-xim pixel teeb tsa thiab SMD1515 ntim tshuab, nws muab cov xim tshwj xeeb rau kev ncaj ncees, raug tsim tawm hom VI xim thiab cov khoom tones. Piv txwv li, thaum tso cov ntawv tshaj tawm zaub mov hauv khw noj mov, cov khoom xyaw liab thiab cov zaub ntsuab tau ua kom pom tseeb los ua kom muaj kev xav 'tshiab', ua rau muaj txiaj ntsig zoo rau cov neeg siv khoom noj.
Kev hloov pauv huab cua tsis muaj kev txwv ib puag ncig: 700cd / ㎡ brightness theem ua haujlwm nruab hnub ci ntsa iab thaum tso cai rau phau ntawv dimming rau kev nplij siab hmo ntuj. Txawm hais tias tsim los rau kev siv sab hauv tsev, nws cov modules kaw kom ruaj khov txawm tias muaj plua plav me me los yog ya raws, ua rau nws zoo tagnrho rau ntau qhov chaw xws li khw malls thiab chaw ua haujlwm.
Daim ntawv tshaj tawm kev tshuaj ntsuam dual hom ntawm "ib chav tsev + splicing" ua rau nws haum rau yuav luag txhua qhov kev nthuav qhia sab hauv tsev, nrog tus nqi kev ua tau zoo dua li cov khoom siv ib txwm muaj.
Daim ntawv thov ib leeg-chav xwm txheej: * Khw muag khoom: tso saib qhov rais kev tshaj tawm thiab cov dab neeg ntawm lub rooj sib tham pem hauv ntej; * cheeb tsam chaw ua haujlwm: Roll tuam txhab ntawv ceeb toom hauv chav tshuaj yej thiab qhia cov sij hawm sib tham ntawm qhov nkag ntawm chav sib tham; * Cov khw muag khoom me: Cov khw muag khoom yooj yim thiab cov khw kas fes tso tawm cov npe khoom tshiab thiab cov txiaj ntsig ntawm cov tswv cuab.
Ntau lub vijtsam splicing daim ntaub ntawv: *Exhibitions: tso saib cov khoom promotional yeeb yaj duab ntawm loj cov ntxaij vab tshaus kom nyiam passersby; * Txheej xwm: Siv ua cov ntxaij vab tshaus tom qab rau cov rooj sib tham me me thiab kev cob qhia los qhia cov ntsiab lus thiab cov qhua tuaj noj mov; * Cov chaw ua haujlwm loj: Nruab cov phab ntsa kab lis kev cai ntawm cov chaw txais tos neeg thiab tso cov ntawv tshaj tawm hauv cov chaw tos txais hauv pem teb.
Core Parameters Txheej txheem cej luam
| Parametercqeb | Cov kev txwv tshwj xeeb | tus nqi tseem ceeb |
| Basic Specifications | Screen cheeb tsam: 1.2288㎡ (0.64m × 1.92m) ; qauv: P1.86-43S | Chav tsev muaj qhov loj me me thiab haum rau qhov chaw me me. Tus qauv sib raug rau HD configuration. |
| Qhia core | Pixel: 1.86mm; ceev: 289050 dot / ㎡; 1R1G1B | Ultra HD nthuav dav, muaj tseeb xim luam tawm, daim duab tiag tiag |
| Koom nrog thiab Tswj | Module: 320 × 160mm; chaw nres nkoj: HUB75E; 1/43 scan | Standardized modules rau seamless multi-unit kev koom ua ke; ruaj khov thiab synchronized video zaub |
| Portability thiab kev siv zog | Qhov hnyav: 0.369KG; Thickness: 14.7mm; Lub zog: 20W | Portable nrog ib txhais tes, kev siv hluav taws xob tsawg, thiab tus nqi siv sij hawm tsawg |
| Saib kev paub | Brightness: 700cd / ㎡ ； refresh: 3840HZ ； Saib nrug 2-20M | Ntshiab thaum nruab hnub, tsis muaj flicker; npog ntau qhov kev pom deb |
Txawm hais tias koj xav hloov koj lub khw nrog "lub sijhawm hloov kho hluav taws xob hauv lub sijhawm tiag tiag" lossis xav tau "rov siv tau rov siv dua splicing screen" rau kev nthuav qhia, qhov PI-P1.8MM-zoo li lub xov tooj ntawm tes splicing LED daim ntawv tshuaj ntsuam tuaj yeem ua tau raws li qhov xav tau. Nws tsis yog tsuas yog ib qho screen xwb, tab sis kuj yog "kev daws teeb meem" uas tuaj yeem hloov kho tau yooj yim rau cov xwm txheej sib txawv.
